Additional Information
| General | |
|---|---|
| Manufacturer | Baader Planetarium |
| SKU (#) | 2954325 |
| EAN Code | 4047825101938 |
| Net weight (kg) | 0.14 |
| Specifications | |
| Focal Length | 25 mm |
| Apparent Field of View | 40° |
| Eye Relief (mm) | 15,5 mm |
| AR-Coating | Phantom Coating® Group |
| Speciality | Cross Aim |
| Eyepiece Design | |
| Field Stop Diameter | 18 mm |
| Number of Lens Elements | 3 |
| Number of Groups | 2 |
| Outer Diameter | 36 mm without illumination housing |
| Connections | |
| Inner Connection (lens sided) | Thread, T-2 (M42 x 0,75) |
| Threaded for filters | Yes |
